The Polycrystalline Silicon Machine Poly Cells Maker is available to produce super bubble sheet of three layers and two sides in different diameters of 5m/m, 10m/m, and 25m/m. The unique design of two shafts makes the thickness adjustable and able to assembly bi-color poly cells making machine. Do not hesitate to contact us for further information!
Product Features
| Ky100-1500-2AB | Ky120-2400-2AB | |
|---|---|---|
| Type | 2-Ply Bubble | 2-Ply Bubble |
| Sheet Width (Max) | 1500mm | 2400mm |
| Film Thickness | 0.02-0.15mm | 0.02-015mm |
| Production Speed (Max) | 30 Meters/Min | 30 Meters/Min |
| Extruder | ||
| Screw Diameter | 100mm & 75mm | 120mm & 90mm |
| Screw L/D Ratio | 30/1 | 30/1 |
| Driving Motor | 75HP & 40HP | 100HP & 75HP |
| Extruding Capacity | Max. 170KGS/Hour | Max. 360KGS/Hour |
| Auto-Therom Control | 2 Sets | 2 Sets |
| Heating Zone | 5 Zones & 4 Zones | 5 Zones & 4 Zones |
| Heating Capacity | 38KW & 30KW | 38KW & 32KW |
| Brake Motor | 2HP | 2HP |
| T-Die | ||
| Die Lip Width | 1625mm | 2525mm |
| Type of Lip | 2X1 & 1x1 | 2X1 & 1X1 |
| Auto-Therom Control | 2 Sets | 2 Sets |
| Heating Zone | 7X2 Zones | 9X2 Zones |
| Heating Capacity | 33KW & 18KW | 40KW & 18KW |
| Take-OFF Unit | ||
| Take-Up Roller | ψ150X1625mm | ψ150X1625mm |
| Driving Motor | 2HP | 2HP |
| Edge Trimmer | 1Set | 1Set |
| Trimming Blower | 1HP | 1HP |
| Former Unit | ||
| Forming Roller | ψ400X1625mmW | ψ400X2525mmW |
| Silicon Rubber Roller | ψ275X1625mmW | ψ275X2525mmW |
| Laminating Roller | ψ200X1625mmW | ψ200X2525mmW |
| Cooling Roller | ψ100X1625mmW | ψ100X2525mmW |
| Driving Motor | 5HP | 10HP |
| Motor of Vacuum Pump | 7.5HP | 15HP |
| Winder | ||
| Type | 2 Air Shafts Turret | 2 Air Shafts Turret |
| Tension Controller | Adjust. Elec. Controller | Adjust. Elec. Controller |
| Winding Motor | 1X2HP | 1X2HP |
| Drive Brake Motor | 1HP | 1HP |
| Wind-Up Diameter | 1200mm | 1200mm |
